HDX Series
Exclusive
HDX Series
Modern Solar Street Lighting
Architectural design. Off-grid performance.
The HDX Series is a high-performance all-in-one solar street light engineered for municipal streets, parking lots, parks, pathways and commercial developments. Combining premium optics, intelligent power management and robust construction, the HDX delivers reliable off-grid lighting while eliminating the need for trenching, underground cabling and utility connections. Designed for projects where performance, efficiency and long-term reliability matter, the HDX is available in outputs from 20W to 120W.
Specifications
Power – 20W–120W LED Luminaire Options
Light Output – Up to 24,000 Lumens
LED Efficacy – Up to 210 lm/W
LED Source – Philips LumiLEDs
Colour Temperature (CCT) – 3000K, 4000K, 5000K, 5700K & 6500K
Solar Panel – High-Efficiency Monocrystalline Silicon Photovoltaic Panel
Battery – Long-Life LiFePO₄ Lithium Battery
Controls – Intelligent MPPT Controller with Optional PIR, Microwave Sensor, Remote Control & IoT Monitoring
Optics – Type II, Type III, Type IV & Type V Roadway Distributions Available
Protection Rating – IP65 Weatherproof
Corrosion Protection – C5 Marine-Class Anti-Corrosion Coating
Operating Temperature – -20°C to +60°C
Construction – Heavy-Duty Die-Cast Aluminum Housing
Mounting Options – Slip Fitter (Standard) or Pole Adapter
Power Options – Off-Grid Solar or Optional Hybrid AC Backup
Installation – Off-Grid Solar Installation – No Trenching or Underground Cabling Required
LED Lifetime – 50,000+ Hours
Key Features
Designed for High-Performance Public Infrastructure
The HDX Solar Street Light is engineered for municipalities, contractors and commercial developments requiring reliable, high-output off-grid lighting. Combining premium LED performance, intelligent solar technology and rugged construction, HDX provides a cost-effective alternative to traditional grid-powered lighting while significantly reducing installation time and infrastructure costs.
Powerful Roadway Performance
Available in outputs from 20W to 120W and delivering up to 24,000 lumens, HDX provides powerful, efficient illumination for roadways, parking lots, parks, pathways and public infrastructure projects.
Premium LED Efficiency
Featuring Philips LumiLEDs with efficacy of up to 210 lm/W, HDX maximises light output while reducing energy consumption and extending battery autonomy.
Intelligent Solar Technology
High-efficiency monocrystalline solar panels work in conjunction with an advanced MPPT charging controller to maximise solar harvesting and optimise battery performance throughout changing weather conditions.
Long-Life LiFePO₄ Battery System
Premium lithium iron phosphate battery technology delivers excellent thermal stability, long service life and dependable overnight operation with minimal maintenance.
Advanced Smart Controls
Available with optional PIR motion sensing, microwave sensors, remote control and IoT monitoring, HDX intelligently manages energy consumption while maintaining safe and reliable lighting performance.
Flexible Optical Distributions
Available with Type II, Type III, Type IV and Type V roadway optics, allowing lighting layouts to be tailored for streets, parking lots, pathways, parks and a wide range of public infrastructure applications.
Engineered for Harsh Environments
Constructed from heavy-duty die-cast aluminium with a C5 marine-class anti-corrosion coating and IP65 weather protection, HDX is built to deliver reliable long-term performance in demanding outdoor environments.
Optional Hybrid Power
For applications requiring additional operational resilience, HDX is available with an optional 100–240V AC hybrid backup, combining the benefits of solar with the reliability of grid power when needed.
No Trenching Required
As a fully off-grid lighting solution, HDX eliminates underground cabling, conduit and electrical infrastructure, reducing installation costs, minimising site disruption and accelerating project delivery.
Flexible Installation Options
Available with standard slip fitter mounting or optional pole adapter configurations, making HDX suitable for new installations, retrofit projects and a wide variety of municipal and commercial applications.
Ideal Applications
Roadways & Streets
Municipal Streets
Residential Streets
Collector Roads
Local Road Networks
Streetscapes & Boulevards
Parks & Recreation
Public Parks
Shared-Use Pathways
Walking & Cycling Trails
Riverwalks & Waterfronts
Sports & Recreation Areas
Commercial & Industrial
Commercial Developments
Industrial Parks
Business Parks
Distribution Centres
Logistics Facilities
Public Infrastructure
Parking Lots
Transit & Bus Stops
Railway Stations & Corridors
Government Facilities
Public Infrastructure Projects
Community Developments
Residential Communities
HOAs & Gated Communities
Universities & School Campuses
Healthcare Facilities
Resorts & Hospitality
Why Choose the COVE Series
✓ High-performance solar street lighting
✓ Up to 210 lm/W LED efficiency
✓ Intelligent MPPT charging technology
✓ Long-life LiFePO₄ battery system
✓ Type II, III, IV & V roadway optics
✓ Optional Hybrid AC backup
✓ Heavy-duty C5-rated die-cast aluminum housing
✓ No trenching or electrical infrastructure
✓ Fast, cost-effective installation
✓ Low maintenance and operating costs
✓ Smart control and IoT ready
✓ Designed for public infrastructure
Warranty Information
5-Year Limited Warranty
The HDX Series is backed by a 5-Year Limited Warranty, providing confidence in long-term performance and product reliability. Designed for municipal streets, parking facilities, parks and public infrastructure, HDX combines robust construction with intelligent solar technology to deliver dependable, low-maintenance lighting for years to come.
